Introduction

The Interstate Bridge Replacement (IBR) program, is preparing a Navigation Impact Report (NIR) to inform the planning and design of a replacement bridge for the Interstate Bridge between Oregon and Washington. The preparation of a NIR is a required element of a bridge permit application to the United States Coast Guard. In order to understand the current and future navigational needs, and vessel characteristics of Columbia River users at the bridge locations over the main Columbia River (River mile 106.5) and the North Portland Harbor (River Mile 3.4), the IBR program is conducting outreach to waterway users.

Please take the following survey to share information about your vessel(s) and how often you travel under the Interstate Bridge and the North Portland Harbor Bridge. Please answer as many questions as possible and complete a new survey for each vessel in your fleet. Additionally, please complete a survey for any vessels in the planning or construction phase that will travel under these bridges. Should you have any questions or need assistance, please reach out to the project team.

Email: rivernav@interstatebridge.org
Call: 360-859-0494 (Washington), 503-897-9218 (Oregon), 888-503-6735 (toll-free), or 711 (ADA)

Thank you for your time!

Question Title

* 1. Company Name

Question Title

* 2. Contact Information

Question Title

* 3. Vessel Name (please complete one survey per vessel)

Question Title

* 4. Vessel Type

Question Title

* 5. Specialized Vessel (e.g. limited maneuverability due to design or mode of operation. If yes, please describe)

Question Title

* 6. Vessel Category

Question Title

* 7. USCG Document Number

Question Title

* 8. Primary Mooring Location (waterway milepoint, if known)

Question Title

* 9. Type and quantity of cargo, if applicable

Question Title

* 10. Length (total feet)

Question Title

* 11. Beam (width in feet)

Question Title

* 12. Draft (feet) - depth of hull below waterline, fully laden

Question Title

* 13. Air Draft (feet) - height of highest fixed point above waterline, unladen

Question Title

* 14. Air Gap (feet) - desired clearance from highest fixed point to lowest part of bridge

Question Title

* 15. Safety Margin (feet) - horizontal clearance required by vessel to navigate through the bridge

Question Title

Columbia River and Oregon Slough/North Portland Harbor Channels

Map showing the location of the main channel of the Columbia River and the Oregon Slough

Question Title

* 16. Frequency of passage under Interstate Bridge (main channel)

Question Title

* 17. Frequency of passage under the North Portland Harbor Bridge (Oregon Slough)

Question Title

* 18. Transit speed under Interstate Bridge and Load Configuration (if applicable)

Question Title

* 19. Tug Assistance Required

Question Title

* 20. Please identify any future vessel, cargo, and/or business plans that might require different vessels to transit under the bridge. If plans are available online, please provide a link to the online source or email the plans to rivernav@interstatebridge.org.

Question Title

* 21. Is there anything else you would like to add about your vessel or business plans?

Question Title

* 22. Do you have another vessel?
